Grade: SGCC, SGCH, DX51D
Standard: JIS, ASTM, GB, DIN
Hardness: Full hard, half hard, Soft
Zinc Coating: 40 - 275g/m2
Coil ID: 508mm,610mm
Surface processing: Mini Spangle, Regular Spangle, Big Spangle
Basic material: cold rolled steel coil
Coil weight: 3–8mt
Thickness: 0.12mm-2.5mm
Width: 600mm-1250mm
Product Introduction
The hot-dip Al-Zn coated steel is a kind of coated steel. With the cold rolled steel of different strength and thickness as substrate, it is produced through applying Al-Zn coat on both faces by hot dip process. In this coating, Al accounts for about 55%, Si 1.5%, Zn 43.5%. It enjoys both the physical protective property of Zn. And its surface has bright silver color and regular embossed-like figure, which are highly decorative.
Specification
| Products Name | Galvalume Steel Coil |
Thickness | 0.12mm–2.5mm |
Width | 600MM–1250MM |
Grade | JIS G3321 SGCC, SGLC400 —570, (G550), EN10346 -DX51D + AZ, DX53D + AZ, ASTM A792M |
Aluzinc Coating | AZ 30—AZ 185gr/m2 |
Surface | Unoiled /Slight Oiled / Dry/ Anti-finger |
Spangle | Regular spangle, small spangle, big spangle |
Chemical Treatment | Chromated (Cr 3+, 6+, 0+) |
Coil Weight | 3-6 Ton |
Coil ID | 508 / 610 mm |
Packing | Export Standard Packing |
Hardness | Soft (normal), hard, full hard (G300-G550) |
HS code | 72104900 |
Main Feature
1) Galvalume steel is formable, weldable and paintable.
2) Galvalume steel has superior corrosion resistance in the most atmospheric conditions. This is achieved through the combination of the sacrificial protection of the zinc and the barrier protection of the aluminum.
3) Galvalume Steel coating out-perform galvanized coating from 2-6 times than hot dip galvanized steel.
Application
1. Architecture: roofs and outside walls of civilian and industrial building, rage doors, fencings and window blinds.
2. Industrial Instruments: electric control cabinet, industrial refrigeration equipment and matic vending machine.
3. Appliances Industry: outer clad sheets for air conditioner and ventilation system, explosion-proof strip, solar water heater and appliance parts.
4. Other: muffer, heat shields of exhaust pipe and catalytic converter, auto parts & accessories under the frame, signboard in highway.
Packing & Delivery
Standard Export Packing: extra reinforcement before shipment to ensure that the goods are safer and less damaged to customers.
* 4 eye bands and 4 circumferential bands in steel.
* Galvanized metal fluted rings on inner and outer edges.
* Galvanized metal and waterproof paper wall protection disk.
* Galvanized metal and waterproof paper around circumference and bore protection.
Why Choose Us?
1, ISO, BV, CE, SGS approved.
2, Competitive price and quality from our own factory.
3, Efficient service team online for 24 hours.
4, Smooth production ability (50000tons/month).
5, quick delivery and standard exporting package.
6, Flexible payment with T/T, L/C, Paypal, Kunlun bank, etc.
