SPCC Steel -DC01/St12 Cold Rolled Steel Sheet & Strip



What is SPCC Steel ?



SPCC steel refers to a type of cold-rolled steel, and it stands for "Steel Plate Cold Commercial." It is a Japanese industrial standard (JIS G 3141) used to define the material characteristics of cold-rolled carbon steel sheets and strips. SPCC steel is known for its excellent formability, smooth surface finish, and consistent thickness.







Here's a breakdown of the term:



1. Steel Plate Cold Commercial (SPCC): This indicates that the steel is intended for commercial use and has undergone a cold-rolling process. Cold-rolling involves reducing the thickness of the steel by passing it through rollers at low temperatures.

2. JIS G 3141: This is the Japanese Industrial Standard (JIS) that specifies the classification, chemical composition, and mechanical properties of cold-rolled carbon steel sheets and strips.

SPCC steel is commonly used in various applications such as automotive components, home appliances, electronic goods, and other products where a smooth and uniform surface finish is required. Additionally, its formability makes it suitable for shaping and bending during manufacturing processes.



SPCC Steel -DC01/St12 Cold Rolled Steel Specification



Product Name	Cold rolled carbon steel sheet
Material	A36,Q235,Q235B,Q345B,Q255,Q275,SS400,A36,Q460A SM400A,St372,SA283Gr,S235JR,S235J0,S235J2
Standard	AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Length	4m-12m or as required
Width	0.5m-3m or as required
Thickness	0.12mm-40mm or as required
Surface	Clean, blasting and painting according to customer requirement
Yield Strength	250~600 MPa
Tensile Strength	350~800 MPa
Packaging	Bundled with strong steel strips or with waterproof packing materials Special packings please discuss with us
Delivery terms	FOB / CIF / CFR / DAP or discuss with us for other terms
Delivery Time	5-30 days after deposit received or L/C received in our bank



SPCC vs Sphc vs SPCD VS SPCE VS SPHD VS SGCC



SPCC -- Cold rolled steel sheet and strip of commercial quality;

SPHC -- Hot rolled steel sheet and strip of commercial quality;

SPCD - Cold rolled steel sheet and strip of drawing quality, which is equivalent to St13/14, DC03/04;

SPCE - Cold rolled steel sheet and strip of deep drawing quality. It similar codes are St15/16, DC05/06;

SPHD -- Hot rolled steel sheet and strip of drawing quality;

SGCC -- Hot dip galvanized cold rolled steel of commercial quality.

SPCC Steel Specifications.



The common specification of SPCC cold rolled sheet is 0.1-3.0 mm*1,250 mm*2,440 mm; The max width and length can reach up to 2,000mm and 6,000 mm.



while the specification of SPCC cold-rolled strip and coil is 0.1-2.5 mm *355-1,500 mm



apan (JIS)	China (GB)	Germany (DIN)	European (EN)	USA (AISI)	Russia (GOST)	Internation (ISO)	England (BS)
SPCC	Q195   Q215A	St12	DC01   (1.0330)	SAE1008   SAE1010	08kp   08ps	Cr01   CR22	FeP01



What Is the Composition of SPCC Steel?

Item	C	Mn	P	S	Si
SPCC	≤0.15	≤0.60	≤0.1	≤0.025
Q195	0.06~0.12	0.25~0.50	≤0.045	≤0.05	≤0.30
Q215A	0.09~0.15	0.25~0.55	≤0.045	≤0.05	≤0.30
Q235A	0.14~0.22	0.30~0.65	≤0.045	≤0.05	≤0.30

SPCC Mechanical Properties

Yield Strength	Tensile Strength	Elongation
140~280 (Mpa)	≥270 (Mpa)	0.25-2.5mm	≥2.5mm
		≥34	≥34

SPCC (Steel Plate Cold Commercial) steel is widely used in various applications due to its favorable characteristics, which include good formability, surface finish, and consistent thickness. Some common applications of SPCC metal include:



1. Automotive Industry: SPCC steel is used in the manufacturing of automotive components, such as body panels, fenders, doors, and other structural parts. Its formability allows for the production of complex shapes, while its smooth surface finish contributes to the aesthetic appeal of the finished products.

2. Home Appliances: SPCC is commonly employed in the production of home appliances like refrigerators, washing machines, air conditioners, and microwave ovens. The material's consistent thickness and surface finish make it suitable for these applications.

3. Electronic Goods: SPCC steel is used in the manufacturing of electronic components and devices, including computer cases, audio equipment, and other consumer electronics. Its formability is beneficial for creating intricate and compact designs.

4. Construction: While not as common as in other applications, SPCC steel can be used in certain construction applications, especially where a smooth surface finish is desired. It may be used in interior components or decorative elements.

5. Containers and Packaging: SPCC steel is also utilized in the production of containers, cans, and packaging materials. Its ability to be formed into precise shapes is valuable for creating containers with specific dimensions.

6. General Manufacturing: SPCC steel finds use in various general manufacturing processes where cold-rolled steel with specific characteristics is required. Its versatility makes it suitable for a wide range of industries.

It's important to note that the specific application of SPCC steel may depend on the desired properties of the final product and the manufacturing processes involved. The material's characteristics make it well-suited for situations where a combination of formability, surface finish, and consistent thickness is crucial.



In conclusion





SPCC stands for "Steel Plate Cold Rolled Commercial," and it refers to a grade of cold-rolled steel. Its excellent formability, strength, and resistance to rust and corrosion make it a popular choice for a variety of applications. If you have any questions, please feel free to contact us!
