Dx51d Zinc Coating Spangle 30-275g Galvanzied Coils0.32 0.42x1000,0.32x0.42x1250

Dx51d zinc coating 30-275g Galvanised Coils0.32 0.42x1000,0.32x0.42x1250 Description





Width:	600mm-1250mm	Standard:	ASTM
Length:	Coil	Grade:	DX51D Z30-275
Application:	Roofing,Decor,Flange Plate,commercial Use	Technique:	Cold Rolled
Coil Weight:	2.5-8ton	Type:	Steel Coil
Surface Treatment:	Galvanized	Surface:	Galvanized Coated,chromated And Oiled
Thickness:	0.1-3.0
High Light:	1.2mm galvanized steel coils , dx51d z275 galvanized steel coils , regular hot dip galvanized steel strip





Specification of our galvanized steel coil

Name	Galvanized Steel Coil
Base metal	Galvanized Steel Coils
Productivity	200,000mt/year
Thickness	0.1-3mm
Width	1000mm, 1250mm
Coil Weight	3-8 MT
Zinc coating	Z40 - Z275
Inside Diameter	508mm Or 610mm
Zinc Coating	Customer
Standard	Commercial Grade: SGCC, JIS G3321, DX51D, EN1042 or ASTM A792M Structure Grade: S280GD, S350GD, G550, FULL HARD GRADE
Surface Treatment	oiled / non-oiled
Quality Guarantee	15-20 years of outdoor durability
Spangle	None Spangle / Regular Spangle / Small Spangle / Large Spangle

Available Chinese Mill: WISCO,Capital Steel(Shougang), Ansteel, Baotou, Lianyuan, Tangshan, Jinan, Panzhihua, Kunming, etc and some small mills

 GI Products type we can provide

Products Type	Size range	Packing details	Weight	Noted
Galvanized steel sheet	0.25 - 3.0mm x 1000*2000mm/1250*2500mm/1500*3000mm	Packing by wooden pallets	within 3 ton each packing	cuntoms length as request
Galvanized steel coil	0.12 - 3.0mm x 1000/1250mm/1500mm x Coil	packing by wooden frame	weight: 2 - 8 Tons	we can devide into small coils
Galvanized steel strips	0.12-3.0mm x Width 10 - 1500mm x Coil	packing by wooden pallets	weight: within 3 Tons	custom size as request

Dx51d zinc coating 30-275g Galvanised Coils Features



1. Hot-dip galvanized steel sheet/plate is characterized by long service life, high corrosion resistance and bright surface.

2. Hot-dip galvanized steel has excellent forming properties, paintability and weldability, which is suitable for forming, pressing and bending processing.

About the surface

Regular Spangle :

Regular zinc flower, also known as ordinary zinc flower, is naturally formed in the galvanizing process, without any additional treatment.

Mini Spangle:

Zinc blooms are suppressed and mini zinc blooms are formed by reducing the lead content in the zinc solution or by blowing out the zinc powder through a device mounted on the zinc pot.

mini spangle:

The mini spangle are further leveled to produce an extra smooth surface.

Dx51d zinc coating 30-275g Galvanised Coils Applications:

1. Construction: Roofs and roof components, facades of civil and industrial buildings, garage doors and shutters.

2. Household appliances: washing machines, refrigerators, televisions, air conditioning and ventilation systems, vacuum cleaners, solar water heaters.

3. Vehicles: automobile ceilings, automobile industry mufflers, exhaust pipes and catalytic converter heat shields, ship bulkheads, highway guardrails.

4. Industry: industrial instrumentation and electrical control cabinets, industrial refrigeration equipment, vending machines 5.

5. Furniture: lampshades, counters, signs, medical facilities, etc.



Our company is engaged in galvanized sheet, galvanized coil processing, trade service enterprises; Our company is close to Shanghai port, which has a very good export advantage. Our company has established a good cooperative relationship with shougang, Angang, Handan, Tang Steel, Bensteel, Baosteel and other large steel mills.

Advantages of the Li Cheung Company:

Li Cheung Steel Advantages

1. Have The Ability To Design And Develop.

2. Our Development Department For New Material Research Is Non-Toxic, Odorless, And Impermeable.

3. We Have Customers In Over 50 Countries And Production On A Large Scale, Thus We Have A Price Advantage. Good Experience And Cooperation With Big Clients In The World;

4. With Certificate ISO9001-2008.

5. Sample Order Is Acceptable.

6. Good Communication Skills, And Good Service Understanding For Customers.



Superiority



1. Good corrosion resistance

2. Qualified machinability

3. High heat resistance

4. Excellent reflectivity

5. Low price and remarkable effect

6. Can be recycled and reused multiple times

Q1: How do you guarantee the quality?

A1: ①We have passed ISO9001, SGS, CE, and other certifications;

②Always have pre-production samples before mass production, and always do final inspection before shipment;

③Acceptable third-party inspection.

Q2: Can you arrange the shipment?

A2: Sure, we have a permanent freight forwarder who can gain the best price from most ship company and offer professional service.

Q3: How long is your delivery time?

A3: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to quantity.

How can we get the offer?

Please offer the specification of the product, such as material,size,shape,etc. So wecan give the best offer.

Q5:How can I get one sample for testing?

A5:Free sample: We'd love to send you free samples which have in stock, and you just need arrange shipment. Charged sample: $100 for sample developed, and return after mass production

Q6: How do you make our business long-term and good relationship?

A6: (1)We keep good quality and competitive price to ensure our customers' benefit. (2) We respect every customer as our friend and we sincerrly do business and make friends with them, no matter where they come from.

If you need welcome to contact us!

Email: sales@licheungsteel.com

WhatsApp:http://wa.me/8613213178890
